[Instrument Features]

1．Colorful PLC integrated display and control box with menu-based operation mode.

2．No radial swing, no jumping or vibration during operation.

3．Driven by a precision high-grade motor, ensuring stable operation with low noise.

4．Supports inching adjustment, and the tool rest automatically resets.

5．Tungsten steel blade with high hardness and standard friction head weight.

6．Replaceable sample stage, enabling multi-position testing.

7．Equipped with inductive detection; the instrument automatically stops when cutting penetration occurs.

[Technical Parameters]

1．Load on the blade: (5±0.5)N.

2．Movement stroke: 50mm.

3．Cutting speed: Maximum sinusoidal cutting speed up to 8±2cm/s.

4．Blade requirements: Circular blade with diameter (45±0.5)mm and thickness (0.3±0.03)mm.

5．Total cutting angle: 30°-35°; the blade shall be tungsten steel with a hardness of (700-720)HV.

6．Test piece size: 100×60mm.

7．Counting range: 0-999999.

8．Dimensions: 580×160×430mm.

9．Weight: 60kg.

10．Power supply: AC220V, 10A.
