【适用范围】

Specialized for medical equipment such as extracorporeal circulation systems, hemodialysis machines, and cardiopulmonary bypass machines. It achieves stable blood delivery through non-contact peristaltic drive, complying with YY 0503-2016 "Cardiovascular Implants and Extracorporeal Systems" standard. Suitable for operating rooms, ICUs, blood banks, and other scenarios, ensuring biocompatibility and fluid delivery accuracy (error ≤±5%).

【相关标准】

None

【Technical Parameters】

1．Flow Rate Range: 10～250ml/min (ф6mm), 20～460ml/min (ф8mm);

2．Flow Rate Accuracy: ±10%;

3．Total Presettable Volume Range: 0～9999ml;

4．Operation Mode: Membrane keys;

5．Reminder Function: Audible alert when the accumulated volume reaches the preset value;

6．Automatic Pump Stop: None;

7．Dimensions: ≥245×165×285mm (L×W×H);

8．Weight: ≤6kg;

9．Noise Level: ≤60dB;

10．Digital Display Function: Shall display pump tube inner diameter, flow rate, preset volume, and accumulated volume.

【Accessories List】

Main unit: 1 piece;

Power cord: 1 piece.
