【适用范围】

Used for measuring the diameter of animal fibers, chemical fibers, cotton, linen and other fibers. It can obtain the number of fibers, average fineness of fibers, standard deviation, coefficient of variation, and coarse fiber content. Through morphological analysis and diameter measurement of single fibers in blended products, the fiber content of various blended products can be obtained, including the blended content of yarns and fabrics.

【相关标准】

GB/T 10685-2007 "Test Method for Diameter of Wool Fibers - Projection Microscope Method"GB/T 20732-2006 "Optical Fiber Diameter Analyzer"GB/T 3364-2008 "Test Method for Diameter and Number of Carbon Fibers"FZ/T 01057.3-2007 "Test Methods for Identification of Textile Fibers - Part 3: Microscope Method"AATCC 20-2013 "Fiber Qualitative Analysis"IWTO-47-2009 "Specification for the Determination of Average Diameter and Distribution of Wool Fibers by Optical Fiber Diameter Analyzers"IWTO-8-2004 "Method for Determining the Diameter Distribution of Wool Fibers and the Medullation Percentage of Wool and Other Animal Fibers by Microprojection"ISO 137:2015 "Wool - Determination of Fiber Diameter - Projection Microscope Method"GB/T 12412-2007 "Yak Hair"GB/T 9998-2006 "Xining Wool"GB/T 18267-2013 "Cashmere"GB/T 16988-2013 "Determination of the Content of Special Animal Fibers and Their Mixtures with Cotton and Wool"GB/T 16254-2008 "Mohair"GB/T 13835.6-2009 "Test Method for Fineness of Rabbit Hair Fibers"GB/T 21977-2008 "Camel Hair"FZ/T 30003-2009 "Quantitative Analysis Method for Hemp/Cotton Blended Products - Microprojection Method"FZ/T 32004-2009 "Grey Yarn of Linen/Cotton Blends"SN/T 0756-1999 "Quantitative Analysis Method for Imported and Exported Hemp/Cotton Blended Products - Microprojection Method"ISO 17751:2007 "Animal Fibers - Quantitative Microscopic Analysis - Cashmere, Wool, Other Animal Down and Their Mixtures"FZ/T 01101-2008 "Textiles - Determination of Fiber Content - Physical Method"AATCC 20A-2014 "Specification for Quantitative Fiber Analysis"FZ/T 50002-1991 "Test for Profilation Degree and Hollow Ratio of Profiled Fibers"

[Instrument Features]

1．National standard measurement range: 2~200μm; Instrument measurement range: 1~2000μm.

2．Equipped with data calibration function, full sample image archiving function, and Chinese menu.

3．Data and reports are output in EXCEL format; report format and statistical methods can be modified according to relevant standard requirements provided by users.

4．Developed personalized interface with customizable observation magnification.

5．Automatic scale calibration to minimize operational errors.

6．Dynamic measurement added for diameter tests and content tests; measurement marks of the current field of view can be retained, greatly improving measurement speed and accuracy.

7．Used for observing the cross-sectional morphology and measuring the cross-sectional area of various chemical fibers, profiled fibers, and hollow fibers.

8．Testing of profilation degree and hollow ratio of profiled fibers complies with textile industry standards.

9．Fiber content of various blended products can be obtained through cross-sectional morphological analysis and area measurement of single fibers in blended products.

10．Adopts dynamic measurement mark automatic induction technology.

11．Fiber type user-defined technology allows users to customize fiber types.

12．Provides a fiber sample library with more than 50 fiber types.

Metrological Certification: Micrometer is equipped with test certificates provided by the National Institute of Metrology, China and the National Textile Metrology Station, China.

[Microscope Parameters]

Microscope Model: MOTIC B1 (Objectives: 4X, 10X, 20X)Camera Model: Panasonic CP750

1．High-definition image quality: 700 TV lines.

2．High-sensitivity day/night conversion function: 0.08Lux (color mode); 0.008Lux (black and white mode).

3．Electronic sensitivity enhancement: Automatic (up to 32x); Manual (up to 512x).

4．Electronic shutter speed: 1/50s to 1/120000s.

5．Fog penetration compensation: Clear images can be obtained in hazy weather.

Configuration: Lenovo (Yangtian) Computer, Printer
