【适用范围】

Used for determining the abrasion resistance, pilling performance and surface changes of woven fabrics, knitted fabrics, pile fabrics, coated fabrics and nonwovens.

【相关标准】

GB/T 21196, GB/T 4802.2, GB/T 13775, FZ/T 20020, ISO 12945-2, ISO 12947,ASTM D4966, ASTM D4970, ASTM D3886, JIS L1096, IWS Tm196/ TM112

【Instrument Features】:

1．Standard Lissajous curve (Abrasion curve, Pilling curve)

Abrasion curve       Pilling curve

2．Weights and key components are made of 304 stainless steel, featuring an attractive appearance and long service life.

3．Pressure plates are made of special aluminum alloy to ensure no deformation after long-term use.

4．Needle bearing connection and transmission ensure no error in testing of each workbench.

5．Multiple sets of operating programs can be preset, with various counting modes (add counting and subtract counting).

6．Four stations with independent cumulative counting; single station can be locked at any time for convenient test management.

【Technical Parameters】:

1．Number of Stations: 4 stations

2．Counting Range: 0～999999 cycles

3．Stroke: Horizontal: 60.5±0.5mm, Vertical: 24±0.5mm

4．Mass of Loading Objects:

a. Clamp: 198±2g

b. Garment fabric sample weight: 395±2g

c. Furniture decoration sample weight: 594±2g

d. Type B clamp: 155±1g

e. Stainless steel disc: 260±1g

5．Effective Friction Diameter of Abrasive Block:

Type A 198g (1.96N) friction head: Φ28.65 ±0.05mm

Type B 155g (1.52N) friction head: Φ90 ±0.10mm

6．Relative Movement Speed between Clamp and Abrasive Table: 50±2r/min (adjustable from 20-70r/min)

7．Mass of Sample Mounting Weight: 2385±10g

8．Overall Dimensions: 600×550×410mm

9．Power Supply: AC 220V 50Hz 500W

10．Weight: 75kg
