【适用范围】

It is used for the determination of various woven fabrics and non-woven fabrics with regular tearing directions. It is also applicable for testing in industries such as paper, plastic sheets, and electrical tape.

【相关标准】

GB3917.1；FZ/T60006；FZ/T75001；ASTM D1424；ISO13937.1；ISO1974/9290；ASTM D5734等。

[Scope of Application]

It is used for the determination of various woven fabrics and non-woven fabrics with regular tearing directions. It is also applicable to the determination in industries such as paper, plastic cloth and electrical tape.

[Applicable Standards]

GB3917.1; FZ/T60006; FZ/T75001; ASTM D1424; ISO13937.1;

ISO1974/9290; ASTM D5734, etc.

[Technical Parameters]

1．Measuring Range: 0～16N; 0～32N; 0～64N;

2．Minimum Division Value: 0.2N;

3．With Small Weight Added: 0.4N;

4．With Large Weight Added: 0.8N;

5．Notch Length: 20±0.2mm;

6．Force Measurement Error: ≤±1 division;

7．Overall Dimension: 400×210×395mm;

8．Net Weight: 35kg.
