【适用范围】

Used for determining the tear strength of woven fabrics, thin nonwovens and various coated fabrics.

【相关标准】

GB/T3917.1   FZ/T60006  FZ/T75001  ASTM D1424  ISO13937.1  ISO1974/9290   ASTM D5734等.

【Scope of Application】

Used for determining the tear strength of woven fabrics, thin nonwovens and various coated fabrics.

【Compliant Standards】

GB/T3917.1, FZ/T60006, FZ/T75001, ASTM D1424, ISO13937.1, ISO1974/9290, ASTM D5734, etc.

【Technical Parameters】

1.Tear force range: 0～16N

A: 0～32N (with small weight A installed)

B: 0～64N (with large weight B installed)

2.Tear length: 43mm

3.Notch length: 20±0.2mm

4.Sample size: 100(L)×63(W)mm

5.Force measurement accuracy: ≤±1 division

6.Overall dimension: 400(L)×210(W)×400(H)mm

7.Weight: approx. 30Kg
